Triaxial Load Cell, Transducer Model ZFL-3B
Nta:
Strain gauge technology, integrated khoom
High precision, ruaj khov thiab txhim khu kev qha kev ua haujlwm
Tshawb xyuas qhov chaw peb-dimensional
Haum rau neeg hlau tes tiv thaiv overload, automation cov cuab yeej, thiab cov chav kuaj
Qhov Loj (mm)
|
Tsis muaj |
|
|
Muaj peev xwm: |
50N -200KN |
|
Qhov tseeb: |
0.1% F.S, 0.3% F.S |
|
Rated Tso zis: |
1.0-1.5±{3}}.15mV/V, 4-20mA,0-10V (Yeem) |
|
Zero balance mV/V: |
±1.0 |
|
Input resistance: |
350/700 ± 10 Ohm |
|
Cov zis tsis kam: |
350/700 ± 10 Ohm |
|
Rwb thaiv tsev tsis kam: |
Ntau tshaj lossis sib npaug rau 2000 (100VDC) |
|
Temp. Qhov cuam tshuam rau ncua (% FS / 10 degree): |
±0.5 |
|
Temp. cuam tshuam rau xoom (% FS / 10 degree): |
±0.5 |
|
Siv temp. Ntau yam (degree): |
-20-+60 |
|
Kev tawm dag zog (V): : |
12 VDC |
|
Kev nyab xeeb tshaj (%FS) |
150% |
|
Qhov kawg overload (%FS) |
180% |
|
Tiv thaiv qib |
IP65 |
|
Cable Length: |
3 meters, lwm qhov ntev muaj |
|
Khoom siv |
Alloy hlau, hlau alloy, stainless hlau |
|
Hlau kev twb kev txuas: |
12 cev |
